The FEP tearable heat shrink tubing is made of fluorinated ethylene propylene material through a single extrusion process. It has a standard shrink ratio of 2:1, specifically designed for the shaping and welding processes of medical micro catheters. After shrinking, it tightly adheres to the substrate, and during the peeling process, it is unlikely to scratch the internal products, thereby eliminating the problem of catheter scratches at the source and effectively reducing the production scrap rate.

The heat shrink temperature and processing parameters of this product are the same as those of ordinary FEP heat shrink tubing. The existing production equipment does not need to be modified or replaced, reducing the post-processing procedures, improving the product yield and production line capacity, and being widely used in the processing of various micro medical catheters such as neurointerventional and balloon catheters.

Product features:

• The minimum heat shrink inner diameter is 0.4mm, supporting customization of smaller non-standard inner diameter specifications

• The shrink ratio is 2:1, with a tight and firm covering and no bulging or loosening issues

• The long-term working temperature is 204℃, and the heat shrink processing temperature range is 215℃ ± 10℃

• The inner and outer tube walls are smooth, and the covering process does not scratch the catheter substrate

• The transparent tube body allows for intuitive inspection of the internal workpiece after shrinking, facilitating positioning and quality inspection

• The tearable structure allows for complete peeling along the line with simple tools, without damaging the product

• Simplifies the post-processing process and reduces labor hours

• Effectively avoids scratch during peeling, enhancing the safety of medical device products

Advantages of FEP tearable heat shrink tubing products:

1. Non-destructive peeling, reducing scrap

The special tearable structure ensures that the outer layer of low-hardness medical catheters will not be damaged during peeling, solving the problem of catheter scratches and scrap in long-term production, and being suitable for high-end minimally invasive equipment production.

2. Line-wide applicability, no additional investment

The heat shrink process and ordinary FEP heat shrink tubing are completely compatible. Existing ovens and hot air equipment can be directly used without the need to purchase new equipment.

3. Medical base material, stable sterilization resistance

Using high-purity medical-grade FEP raw materials, it can withstand ETO ethylene oxide sterilization, with stable physicochemical properties, suitable for medical device production and processing.

4. Cost reduction and efficiency improvement, simplifying processes

Omitting the fine cutting step, shortening the processing time per piece, improving the overall output of the workshop, and effectively controlling production costs over the long term.

Application scenarios:

1. Various micro catheter forming, welding, and shaping coating sleeves

2. Outer layer protection for balloon catheters during positioning and welding processes

3. Temporary shaping sleeves for minimally invasive intervention equipment processing

FEP tearable heat shrink tubing, with a 2:1 shrink ratio, can be peeled along the line with simple tools without damaging the soft catheter, with a temperature resistance of 204℃, compatible with conventional FEP processing equipment, simplifying the processing procedures of medical catheters, and mostly used for intervention and balloon catheter shaping.

Medical tearable FEP heat shrink tubing, with no trace of peeling, is specifically for micro catheter processing.
